| Electrical Specifications | ||
| Frequency-MHz | 2400-2500 | 4900-7125 |
| Gain-dBi | 4 | 6 |
| VSWR | <1.5 | <2.2 |
| Polarization | Vertical | |
| Horizontal Beam Width | 360° | |
| Vertical Beam Width | 48° | 28° |
| Impedance | 50Ω | |
| Max. Input Power | 50W | |
| Lightning Protection | DC Ground | |
| Mechanical Specifications | ||
| Connector | 6×RP SMA Male | |
| Dimension | Ø128×220 mm | |
| Weight | 1.3kg | |
| Mounting | Mast Ø30-Ø50 mm | |
| Radome Material | UV Resistance PVC | |
| Rate Wind Velocity | 210km/h | |
| Operating Temperature | -40℃ – +65℃ | |
