| Electrical Specifications | |
| Frequency | 5150-5850 MHz |
| Gain | 10 dBi |
| VSWR | <2 |
| Polarization | Horizontal and Vertical |
| Horizontal Beam Width | 360° |
| Vertical Beam Width | 11° |
| Impedance | 50 ohms |
| Max. Input Power | 100W |
| Lightning Protection | DC Ground |
| Mechanical Specifications | |
| Connector | 2×N Female |
| Dimension | Ø84×500mm |
| Weight | 0.6kg |
| Mounting | Mast Ø40-Ø60 mm |
| Radome Material | UV Resistance PVC |
| Rate Wind Velocity | 210km/h |
| Operating Temperature | -40℃ – +65℃ |
