430-470MHz 5.5dBi Outdoor Omnidirectional UHF Base Antenna

Model NO: TOF-43470-6V

  • Operated at 430-470MHz frequency band
  • True 5.5dBi high gain
  • Omnidirectional radiation for outdoor 360 degree signal covered
  • Outdoor pole mount installation
  • Rugged weatherproof fiberglass antenna housing
  • Typical N Female connector

CATEGORIES: VHF/UHF Omni Antenna,
  • Product Detail
Model NOTOF-43470-6V
Electrical Specifications
Frequency430-470 MHz
Gain5.5 dBi
VSWR<1.5
PolarizationVertical
Horizontal Beam Width360°
Vertical Beam Width40°
Impedance50 ohms
Max. Input Power100W
Lightning ProtectionDC Ground
Mechanical Specifications
ConnectorN Female
DimensionØ20×1250 mm
Weight0.75 kg
MountingMast Ø40-Ø60 mm
Radome MaterialFiberglass (White)
Rate Wind Velocity210km/h
Operating Temperature-40℃ – +65℃
