915MHz 9dBi Outdoor Circular Polarized(RHCP) Panel UHF RFID Reader Antenna

Model NO:

TPC-90930-9RC

  • Operated at 902-928MHz frequency band
  • Ideal for RFID, LoRa, ISM, M2M, etc applications
  • True 8dBi gain
  • Right hand circular polarization
  • Outdoor pole mount installation
  • Rugged UV protected ABS antenna housing
  • Dimensions: 250×250×35 mm
  • N Female connector

CATEGORIES:

SHARE:

Electrical Specifications
Frequency902-928 MHz
Gain9 dBi
VSWR<1.5
PolarizationCircular (Right Hand)
Horizontal Beam Width80°
Vertical Beam Width68°
F/B Ratio≥18dB
Impedance50 ohms
Max. Input Power100W
Lightning ProtectionDC Ground
Mechanical Specifications
ConnectorN Female
Dimension250×250×35mm
Weight0.5kg
MountingMast Ø40-Ø60 mm
Radome MaterialABS
Rate Wind Velocity210km/h
Operating Temperature-40℃ – +65℃
