1920-2170MHz 8dBi Outdoor Omnidirectional Antenna

Model NO:

TOF-1921-8V

  • Operated at 1920-2170MHz frequency band
  • True 8dBi high gain
  • Suit for Cellular applications
  • Omnidirectional radiation for outdoor 360 degree signal covered
  • Outdoor pole mount installation
  • Rugged weatherproof fiberglass antenna housing
  • Dimensions: Ø20×750mm
  • Typical N Female connector

CATEGORIES:

SHARE:

Electrical Specifications
Frequency1920-2170 MHz
Gain8 dBi
VSWR<1.5
PolarizationVertical
Horizontal Beam Width360°
Vertical Beam Width18°
Impedance50 ohms
Max. Input Power100W
Lightning ProtectionDC Ground
Mechanical Specifications
ConnectorN Female
DimensionØ20×750mm
Weight0.6kg
MountingMast Ø40-Ø60 mm
Radome MaterialFiberglass (White)
Rate Wind Velocity210km/h
Operating Temperature-40℃ – +65℃
