2.4GHz 19dBi Long Range Parabolic Grid WiFi Antenna

2.4GHz 19dBi Long Range Parabolic Grid WiFi Antenna

Model NO:

TGC-2400-19E6

Operated at 2400-2500MHz frequency band for WiFi
True 19dBi high gain
Ideal suit for outdoor point to point long range connection
Outdoor pole mount installation
Heavy duty mounting brackets
Dimensions: 400×600mm
N Female connector

CATEGORIES：

Parabolic WiFi Antennas, 2.4 GHz Antennas

SHARE:

Electrical Specifications
Frequency	2400-2500 MHz
Gain	19 dBi
VSWR	<1.5
Polarization	Vertical
Horizontal Beam Width	12°
Vertical Beam Width	16°
F/B Ratio	≥25dB
Impedance	50 ohms
Max. Input Power	100W
Lightning Protection	DC Ground
Mechanical Specifications
Connector	N Female
Dimension	400×600mm
Weight	2kg
Mounting	Mast Ø40-Ø60 mm
Rate Wind Velocity	210km/h
Operating Temperature	-40℃ – +65℃
