2G/3G/4G LTE Indoor Wall Mount Directional Panel Antenna 698-2700MHz

Model NO:

TPC-0727-8V

  • Operated at 698-960/1710-2700MHz band for 2G/3G/4G repeater/boosters
  • True 8dBi high gain directional antenna
  • Indoor wall mount installation
  • Rugged UV protected ABS antenna housing
  • Dimensions: 165×155×45 mm
  • 30cm RG58 cable with an N Female connector

SHARE:

Electrical Specifications
Frequency-MHz698-9601710-2700
Gain-dBi78
VSWR<2<1.5
PolarizationVertical
Horizontal Beam Width55°50°
Vertical Beam Width70°60°
Impedance50 ohms
Max. Input Power100W
Lightning ProtectionDC Ground
Mechanical Specifications
ConnectorN Female
Dimension165×155×45 mm
Weight0.5kg
MountingMast Ø40-Ø60 mm
Radome MaterialABS
Rate Wind Velocity210km/h
Operating Temperature-40℃ – +65℃
