698-2700MHz 4G LTE Magnetic Mount Wideband Antenna

Model NO:

TMR-0727-3V

  • Frequency range: 698-960/1710-2700MHz
  • Ideal for 2G/3G/4G/WIFI etc applications
  • Omnidirectional radiation for 360 degree signal coverage
  • Swivel hinged SMA Male connector with 3 meters RG174 coax cable
  • Magnetic mount base

SHARE:

Electrical Specifications
Frequency- MHz698-960/1710-2700
Gain-dBi3±0.5
VSWR<2.5
PolarizationVertical
Horizontal Beam Width360°
Vertical Beam Width65°
Impedance50 ohms
Max. Input Power100W
Lightning ProtectionDC Ground
Mechanical Specifications
ConnectorRP SMA Male
Cable3 meters RG174
Dimension160 mm
Weight35 g
Rate Wind Velocity210km/h
Operating Temperature-40℃ – +65℃
