| Electrical Specifications | ||
| Frequency-MHz | 698-960 | 1710-2700 |
| Gain-dBi | 12 | 17 |
| VSWR | <2 | |
| Polarization | Vertical | |
| Horizontal Beam Width | 65° | |
| Vertical Beam Width | 32° | 8° |
| F/B Ratio | ≥25dB | |
| Impedance | 50 ohms | |
| Max. Input Power | 100W | |
| Lightning Protection | DC Ground | |
| Mechanical Specifications | ||
| Connector | N Female | |
| Dimension | 1600×288×130mm | |
| Weight | 4kg | |
| Mounting | Mast Ø40-Ø60 mm | |
| Radome Material | UV Resistance PVC | |
| Rate Wind Velocity | 210km/h | |
| Operating Temperature | -40℃ – +65℃ |
