2.4/5GHz 13dBi Outdoor Directional Dual Band 4×4 MIMO Panel Antenna

Model NO:

TPC-2458-13BD

  • Operated at 2400-2500/4900-5850MHz dual-frequency band
  • True gain 10dbi@2.4GHz, 13dBi@5GHz
  • Directional antenna for outdoor point to point applications
  • Pole mount for outdoor installation
  • UV Protected ABS antenna housing for weatherproof
  • Dimensions: 250×250×40mm
  • 4×N Female connector
  • IP55 rain and dust resistant

SHARE:

Electrical Specifications
Frequency-MHz2400-25004900-5850
Gain-dBi1013
VSWR<2
Polarization2×Horizontal and 2×Vertical
Horizontal Beam Width50°44°
Vertical Beam Width48°40°
F/B Ratio≥20dB
Isolation≥28dB
Impedance50 ohms
Max. Input Power100W
Lightning ProtectionDC Ground
Mechanical Specifications
Connector4×N Female
Dimension250×250×40mm
Weight0.5kg
MountingMast Ø40-Ø60 mm
Radome MaterialABS
Rate Wind Velocity210km/h
Operating Temperature-40℃ – +65℃
