5.1-5.8GHz 19dBi 2×2 Dual Polarized MIMO WiFi Panel Antenna

Model NO: TPC-5158-19D

  • Operated at 5150-5850MHz frequency band
  • True 19dBi high gain
  • V/H dual polarization
  • Directional antenna for outdoor point to point applications
  • Pole mount for outdoor installation
  • UV Protected ABS antenna housing for weatherproof
  • Dimensions: 305×305×25mm
  • 2×N Female connector
  • IP55 rain and dust resistant

Price:$35.00

$35

* The listed price is for sample only, request a quote from us for bulk order.

CATEGORIES: , ,
Model NOTPC-5158-19D
Electrical Specifications
Frequency5150-5850 MHz
Gain19 dBi
VSWR<1.5
PolarizationHorizontal and Vertical
Horizontal Beam Width17°
Vertical Beam Width17°
F/B Ratio≥23dB
Impedance50 ohms
Max. Input Power100W
Lightning ProtectionDC Ground
Mechanical Specifications
Connector2×N Female
Dimension305×305×25mm
Weight0.7kg
MountingMast Ø40-Ø60 mm
Radome MaterialABS
Rate Wind Velocity210km/h
Operating Temperature-40℃ – +65℃
